Item Specifications:

• Voltage: 12 volts

• Primary OHMs: 4.50 OHMS +/- 0.1

• Secondary OHMs: 20.5k OHMS +/- 0.40

• Mounting Plates: 100mm (End-to-End)

• Mounting points (center to center): 90mm

• Mounting Hole Diameter: 7mm

• Overall width of main body: 33mm

• Overall height of main body: 50mm

• Overall length of main body: 64mm

• Overall length of plug wire: 14"

• Replaces OEM Number: 30400-107-007 / 30400-107-154 / 30400-330-003 / 30530-330-003 / 30530-330-405



Note:

• Only Fit for Vintage Motorcycles' 12 Volts Contact Point.
• This is a RARE and hard to find coil! You may have to modify the wiring and/or mount, but at this price, it's hard to beat.

• If you have the longer or different cap you may have to re-use your existing cap. It just unscrews from the wire.

Package Included:
1 X Ignition Coil

Disclaimer:

NICECNC parts are not sponsored or endorsed by, or affiliated with the brands its parts fit, including KTM, Husqvarna, Honda, Yamaha, Kawasaki, Suzuki, Beta, GASGAS, Sherco, etc.
